Original Audi rear view camera retrofit kit incl. wiring harness for Audi A1 GB Citycarver and Sportback
A rear view camera must be perfectly positioned and deliver excellent image quality – this is exactly why we offer the original camera retrofit kit for your Audi A1. Many modern vehicles have sacrificed visibility for design and safety. In many vehicle models, it is difficult to accurately judge the body dimensions both at the front and rear. Even experienced drivers can easily overlook poorly visible obstacles. Retrofitting a rear view camera can not only prevent scratches, but also help avoid serious accidents.
Function overview:
- Original Audi retrofit kit incl. activation document
- This rear view camera is activated at Audi via SVM
- The equipment "rear view camera" is registered at Audi to the vehicle identification number
- All functions identical to a factory-installed rear view camera
- The rear view camera is discreetly integrated into the tailgate handle trim
- The display appears on the screen of the radio or navigation system
- This camera features dynamic guidelines that display the driving path depending on steering angle
- Automatic camera activation when reverse gear is engaged
- Automatic camera activation via parking assistance button
- The optical parking assistance display remains available (if installed)
- The acoustic parking assistance remains fully functional (if installed)
- Optional Y-hose and washer nozzle for rear view camera available at additional cost
Installation information:
- The installation of the retrofit kit is relatively simple and can also be carried out by experienced hobby mechanics. Just like the factory installation, the camera is mounted in the tailgate and wired among other things to the radio/navigation unit
- After installation, the vehicle must be coded for rear view camera functionality. Our retrofit kit includes an activation document with license protection for this purpose. Activation can only be carried out by an authorized Audi dealership workshop – activation using VCDS, Carly or similar tools is not possible!
The special feature of this activation: the equipment "rear view camera" is officially registered at the factory to your vehicle identification number, meaning your vehicle will no longer differ from one originally equipped with a factory-installed camera.
- Would you prefer to retrofit your "rear view camera" entirely independently and without requiring Audi online activation? This is also possible. Please order our retrofit kit with article number RVC-A1GB. In this retrofit kit, we have already parameterized and pre-coded the camera for you, and the final coding can be completed using VCDS, OBD-Eleven or Carly.
Compatible with the following vehicles:
- Audi A1 GB Citycarver
- Audi A1 GB Sportback
The vehicle must have the following equipment for retrofit:
- MMI Navigation plus (PR number: 7UG)
- MMI Navigation (PR number: 7UF)
- MMI with navigation preparation (PR number: 7UH)
- MMI Radio plus without navigation (PR number: I8V) in combination with DAB+ radio reception (PR number: QV3)
- MMI Radio plus without navigation (PR number: I8W) in combination with DAB+ radio reception (PR number: QV3)
- MMI Radio plus without navigation (PR number: I8V) in combination with dual USB ports (PR number: UI2)
- ...and installed rear parking assistance, front and rear parking assistance or PLA (PR numbers 7X1, 7X2 or 7X5)
(for vehicles without parking assistance please use article number RVC-A1GB!)
As a general rule: if your vehicle is equipped with a navigation system, it also supports rear view camera display = rear view camera retrofit is possible
Would you like to order our retrofit kit but are unsure whether your vehicle meets the requirements? We are happy to provide you with the individual equipment list for your vehicle free of charge – part of our customer service! Please use the subject “Equipment inquiry” in our contact form via the following link: >> to the contact form <<
Scope of delivery:
- 1x Original AUDI A1 GB rear view camera with integrated control unit
- 1x Original Audi rear view camera activation document with license protection
- 1x pre-assembled wiring harness
- Y-hose and washer nozzle for rear view camera (optional)
- 1x installation and coding instructions (German)
Installation time: approx. 3 hours
Notes:
- Please observe the requirements for successful retrofit installation
-
Not suitable for vehicles without parking assistance. For these vehicles, please use our retrofit kit with article number RVC-A1GB
- After installation, the vehicle must be coded for rear view camera functionality. Our retrofit kit includes an activation document with license protection for this purpose. Activation can only be carried out by an authorized Audi dealership workshop – activation using VCDS, Carly or similar tools is not possible!
-
The special feature of this activation: the equipment "rear view camera" is officially registered at the factory to your vehicle identification number, meaning your vehicle will no longer differ from one originally equipped with a factory-installed camera
- If your vehicle does not meet the requirements for retrofitting the original camera (different equipment), a camera retrofit is still always possible – contact us!
Reference numbers / search terms:
- 83A054634A
- 81A827566A
- 81A054733A
- 4M0054800
Professional installation required?
We also offer this item including complete installation at a fixed price. During installation, we parameterize the rear view camera control unit and perform all required coding on the vehicle (additional charge €399.00). If you would also like official factory registration of the retrofit, this is available for an additional charge of €59. The new equipment "rear view camera" will then be officially registered at Audi to your vehicle identification number.
To arrange an appointment, please contact us via our CONTACT FORM. Please always include your vehicle identification number when making inquiries.
Info: Rear view camera calibration is not included in the installation price, however the following applies:
All camera systems supplied by us are pre-configured as accurately as possible, and you will not notice any difference compared to a calibrated camera. If you still require calibration, we are happy to refer you to the neighboring Autohaus Berning (AUDI/VW partner). Estimated costs are approximately €150–200.
